The tester is usually used to test hot crushing strength of different kinds of refractories according to the principle of measuring maximum loading on unit area of materials which is able to uphold at high temperature.
Main parameter
Model Specifications | HCST13-100 HCST15-100 | HCST13-200 HCST15-200 | RMHST16-20Q |
Service temperature | 1300 | 1500 | |
Max.Load | 100 | 200 | 20 |
Measure accuracy | 1 | ||
Loading mode | Frequency conversion loading/servo motor loading | ||
Test atmosphere | Air atmosphere/sample embedded in graghite | seal | |
Sample number,mm、pcs | 3 | 8 | |
Sample Size,mm | Cube with a side length (diameter) of 20-70 | cubes or spheres | |
Structure | conventional structure | Camera monitoring | |
