Using corundum, ceramics, alloys and other internal diameter φ40～φ200mm, can be used in RT～1600 ℃ under long-term stability of the high-temperature furnace tube, its heating length of 200 ～800mm.According to the test purpose and process needs, we provide fast flange interface, convenient operation of various types of professional tube test furnace. It is mainly used for material sintering and synthesizing tests under vacuum or atmosphere protection, and has become the necessary thermal equipment for the majority of material workers.
Main parameter
ModelSpecifications | GSL13-80 | GSL16-80 | HZL13-80 | HZL16-80 |
Service temperature | 1300 | 1600 | 1300 | 1600 |
Heating rate,℃/min | 0-15 | |||
Inner dia,mm | 60-100 optional, default 80 | |||
Hearth size L,mm | 300-600, default 400 | |||
Limit vacuum degree,MPa | -0.1 | |||
Flip angle, ° | 0-30 | |||
Rotary speed,rpm | \ | 0-20 | ||
Quick flange | √ | |||
Furnace tube rotation | \ | √ | ||
